nodget.f File Reference

Go to the source code of this file.

Functions/Subroutines
integer function	nodget ()
	Get first free node of the linked list kept in node array. More...
integer function	nodget_bnd ()
subroutine	makegridlist (lbase)
	Make (modify) array of grid numbers, listOfGrids, (after sorting them in the linked list so they are in decreasing order of workload, done in arrangeGrid()). More...
subroutine	initbndrylist ()
subroutine	makebndrylist (level)
	Preprocess each grid on level level to have a linked list of other grids at the same level that supply ghost cells. More...
subroutine	freebndrylist (mold)
	Free the linked list of intersecting "boundary" grids for grid 'mold' that is no longer active. More...

Function/Subroutine Documentation

freebndrylist()

subroutine freebndrylist

(

integer

mold

)

Free the linked list of intersecting "boundary" grids for grid 'mold' that is no longer active.

The linked list starts at node(bndListSt, mold).

Definition at line 247 of file nodget.f.

References amr_module::bndlist, amr_module::bndlistnum, amr_module::bndlistst, amr_module::nextfree, amr_module::node, and putnod_bnd().

Referenced by gfixup().

c
      use amr_module
      implicit none

      integer nborcount, mold,nextspot, i, nextnext

c :::::::::::::::::::::::::::: freeBndryList :::::::::::::::::::::::::
c     free the linked list of intersecting "boundary" grids for grid 'mold'
c     that is no longer active
c :::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::

           nborcount = node(bndlistnum,mold) ! count for this grid
           nextspot  = node(bndlistst,mold)  ! first index of this grids nbors
           do i = 1, nborcount
               nextnext = bndlist(nextspot,nextfree)
               call putnod_bnd(nextspot)
               nextspot = nextnext
           end do

      return

Here is the call graph for this function:

Here is the caller graph for this function:

initbndrylist()

subroutine initbndrylist

(

)

Definition at line 148 of file nodget.f.

References amr_module::bndlist, amr_module::bndlistsize, amr_module::ndfree_bnd, amr_module::nextfree, and amr_module::null.

Referenced by restrt(), and stst1().

      use amr_module
      implicit none

      integer i
c
c  need to manage the boundary List too
c
      do i = 1, bndlistsize
         bndlist(i,nextfree) = i+1
      end do

      bndlist(bndlistsize,nextfree) = null
      ndfree_bnd = 1

Here is the caller graph for this function:

makebndrylist()

subroutine makebndrylist

(

integer

level

)

Preprocess each grid on level level to have a linked list of other grids at the same level that supply ghost cells.

The linked list is implemented with an array. Each node in this linked list is represented by a row (with 2 elements) in the array, named bndList.

bndList(pos,gridNbor) is grid number stored at node pos bndList(pos,nextfree) is pointer to next node in the linked list

node(bndListSt,mptr) point to the head node in this linked list. Thus bndList(node(bndListSt,mptr),gridNbor) is grid number stored at first node of the linked list.

Definition at line 183 of file nodget.f.

References amr_module::bndlist, amr_module::bndlistnum, amr_module::bndlistst, amr_module::gridnbor, amr_module::listofgrids, amr_module::liststart, amr_module::ndihi, amr_module::ndilo, amr_module::ndjhi, amr_module::ndjlo, amr_module::nextfree, amr_module::nghost, amr_module::node, and amr_module::numgrids.

Referenced by domain(), regrid(), restrt(), and setgrd().

c
      use amr_module
      implicit none

      integer level, n, levst, k, nborcount
      integer nodget_bnd, nextspot, prevnbor, msrc, mptr
      integer imin, imax, jmin, jmax
      integer imlo, imhi, jmlo, jmhi
      integer ixlo, ixhi, jxlo, jxhi

c :::::::::::::::::::::::::::: makeBndryList :::::::::::::::::::::::::
c     preprocess each grid to have linked list of other grids at
c     same level that supply ghost cells.
c :::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::

c     traverse linked list into array. list already sorted by arrangegrids
      levst = liststart(level)
      do n = 1, numgrids(level)
         mptr = listofgrids(levst+n-1)
         imin = node(ndilo,mptr) - nghost  ! ghost cells included since
         imax = node(ndihi,mptr) + nghost  ! this is what you want to fill
         jmin = node(ndjlo,mptr) - nghost  ! may also use for filval stuff,
         jmax = node(ndjhi,mptr) + nghost  ! change nghost to mbuff, etc
         nborcount = 0

         do k = 1, numgrids(level)  ! loop over all other grids once to find touching ones
            if (k .eq. n) cycle     ! dont count yourself as source grid
            msrc = listofgrids(levst+k-1)

            ! Check if grid mptr and patch intersect
            imlo = node(ndilo, msrc)
            jmlo = node(ndjlo, msrc)
            imhi = node(ndihi, msrc)
            jmhi = node(ndjhi, msrc)

            ixlo = max(imlo,imin)
            ixhi = min(imhi,imax)
            jxlo = max(jmlo,jmin)
            jxhi = min(jmhi,jmax)

            if (ixlo .le. ixhi .and. jxlo .le. jxhi) then ! put on bnd list for mptr
               nborcount = nborcount + 1
               nextspot = nodget_bnd()
               bndlist(nextspot,gridnbor) = msrc
               ! get spot in bnd list. insert next grid at front to avoid traversing
               bndlist(nextspot,nextfree) =  node(bndlistst,mptr)
               node(bndlistst,mptr) = nextspot
            endif

         end do

!        save final count
         node(bndlistnum,mptr) = nborcount
      end do

      return

Here is the caller graph for this function:

makegridlist()

subroutine makegridlist

(

integer

lbase

)

Make (modify) array of grid numbers, listOfGrids, (after sorting them in the linked list so they are in decreasing order of workload, done in arrangeGrid()).

This is done every time there is regridding, initial gridding, or restarting. Most often finest level is regridded, so put it last in array. lbase is the level that didnt change, so only redo from lbase+1 to lfine.

Parameters

[in]

lbase

all levels from lbase+1 to the finest get modifed in the array, listOfGrids

Definition at line 109 of file nodget.f.

References amr_module::levelptr, amr_module::lfine, amr_module::listofgrids, amr_module::liststart, amr_module::lstart, amr_module::node, and amr_module::numgrids.

Referenced by domain(), regrid(), restrt(), and setgrd().

c
      use amr_module
      implicit none

      integer lbase, levst, lev, mptr, n

c :::::::::::::::::::::::::::: make_gridList :::::::::::::::::::::::::
c     make array of grid numbers (after sorting them so in decreasing
c     order of workload, done in arrangeGrid and put back into linked
c     list. Done every time there is regridding, initial gridding,
c     or restarting.  Most often finest level is regridded, so
c     put it last in array. lbase is the level that didnt change, so
c     only redo from lbase+1 to lfine.
c :::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::

      !write(*,*)"mgl: lbase,lfine",lbase,lfine
      do lev = lbase+1, lfine
         levst = liststart(lev)
         !write(*,*)"mgl: level ",lev," starts at ",levSt
         mptr = lstart(lev)
c        traverse linked list into array. list already sorted by arrangegrids
         do n = 1, numgrids(lev)
            listofgrids(levst+n-1) = mptr
            mptr = node(levelptr,mptr)
         end do
c
c        next level starts one after where this one ends.
c        Using a sentinel in dimension of
c        listStart so no need to test if level = mxnest
c
         liststart(lev+1) = levst + numgrids(lev)
      end do

      return

Here is the caller graph for this function:

nodget()

integer function nodget

(

)

Get first free node of the linked list kept in node array.

adjust pointers accordingly.

This function is used to create a new grid descriptor, like mptr = new grid_class in c++.

Definition at line 11 of file nodget.f.

References amr_module::lfine, amr_module::maxgr, amr_module::ndfree, amr_module::nextfree, amr_module::node, amr_module::nsize, amr_module::null, amr_module::numgrids, amr_module::outunit, amr_module::rnode, and amr_module::rsize.

Referenced by birect(), domain(), and grdfit().

c
      use amr_module
      implicit double precision (a-h,o-z)

c
c ::::::::::::::::: NODGET ::::::::::::::::::::::::::::::::::::;
c nodget =  get first free node of the linked list kept in node
c            array. adjust pointers accordingly.
c :::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::;
c
      if (ndfree .ne. null) go to 10
          write(outunit,100) maxgr
          write(*,100)       maxgr
100       format(' out of nodal space - allowed ',i8,' grids')
          do level = 1, lfine
             write(*,101) level,numgrids(level)
 101         format("    level ",i4," has ",i7,' grids')
          end do
          write(*,*)" Could need twice as many grids as on any given"
          write(*,*)" level if regridding/birecting"
          stop
c
c  update pointers
c
 10     nodget         = ndfree
        ndfree         = node(nextfree,ndfree)
c
c  initialize new  block
c
        do 20 i        = 1, nsize
           node(i,nodget) = 0
 20     continue
c
        do 30 i         = 1, rsize
           rnode(i,nodget) = 0.0d0
 30     continue
c
      return

Here is the caller graph for this function:

nodget_bnd()

integer function nodget_bnd

(

)

Definition at line 54 of file nodget.f.

References amr_module::bndlist, amr_module::bndlistnum, amr_module::bndlistsize, amr_module::lfine, amr_module::ndfree_bnd, amr_module::nextfree, amr_module::node, amr_module::null, amr_module::numgrids, and amr_module::outunit.

c
      use amr_module
      implicit double precision (a-h,o-z)

c
c ::::::::::::::::: NODGET_BND ::::::::::::::::::::::::::::::::::::;
c nodget_bnd =  same as above but for bndry list
c :::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::;
c
      if (ndfree_bnd .ne. null) go to 10
          write(outunit,100) bndlistsize
          write(*,100)       bndlistsize
100       format(' out of bndry space - allowed ',i5,' bndry grids')
          ! calc average number of bndry nbors per grid
          nbortotal = 0
          numgridstotal = 0
          do lev = 1, lfine
            numgridstotal = numgridstotal + numgrids(lev)
            do mptr = 1, numgrids(lev)
               nbortotal = nbortotal + node(bndlistnum,mptr)
            end do
          end do
          avgnbors = float(nbortotal)/numgridstotal
          write(*,101) numgridstotal,nbortotal,avgnbors
 101      format(" There are ",i8," total grids", i10," bndry nbors",
     .           " average num/grid ",f10.3)

          stop
c
c     ## adjust pointers
c
 10   nodget_bnd      = ndfree_bnd
      ndfree_bnd      = bndlist(ndfree_bnd,nextfree)
c
c     ##  initialize to 0
c
      bndlist(nodget_bnd,1) = 0
      bndlist(nodget_bnd,2) = 0
c
      return
